LED Surtron 80 HP Diathermy Machine

1,200,000.00

SURTRON 80 is a high frequency electrosurgical equipment which is suitable to light and medium surgery.
SURTRON 80, through its performance, allows pure CUT, cut-coagulation BLEND, superficial coagulation FORCED COAG, deep coagulation in absence of necrosis SOFT COAG and, with a special adapter, BIPOLAR coagulation. The digital reading of delivered power and the monitoring of operative function by microcontroller guarantees the absolute reliability of working conditions.
SURTRON 80 allows a highly professional surgery thanks to the user-friendly and safety solutions normally used. The connection of neutral electrode is constantly monitored. Safety control of patient/plate contact using split neutral electrode. The possibility to control by the handle the monopolar output functions as well as the delivery of output power, allows to implement the surgical operation without turning away the surgeon attention from the surgical field.

FEATURES

Max output power CUT: 80 W-250 Ω

Max output power BLEND: 60 W-200 Ω

Max output power FORCED COAG: 50W-150Ω

Max output power SOFT COAG: 40 W-100 Ω

Max output power BIPOLAR: 30 W-100 Ω

Working frequency: 600 KHz

Patient circuit: F

Selectable input voltage: 115-230 Vac

Mains frequency: 50-60 Hz

Electrical input power: 230 VA

Size WxHxD:  254x104x288 mm

Weight: 5 Kgs

CONTROLS

Patient/Plate circuit monitoring

Output power monitoring

Self check control

SAFETY

EN60601-1

EN60601-1-2

EN60601-2-2

Electrical Class: I CF

MDD 93/42/EC Class: II b
