Heal Force Percutaneous Jaundice Meter DHD-C


Jaundice is one of the most common symptoms in the neonatal period. Clinical reports show that 20% to 30% of newborns may have visible jaundice. And early neonatal pathological jaundice is prone to bilirubin encephalopathy, so it is important to screen for early pathological jaundice.
DHD-C Percutaneous Jaundice Meter physical sample and advantages
Large LCD display
Two units displayed at the same time
Average value display, more storage
Lithium battery, long standby time
Continuous measurement, no need to reset

Technical Parameters:

Measurement meth: light reflective
Light source: LED
Display: LCD
Indication error: 0~25 mg/ dL ± 1.0 mg/ dL
Power supply: Lithium battery (DC3.6V, 1000mAh ± 20%);Tests can be done more than 800 times after a fully charge;
Calibration color screen: white end face is 0, yellow end face is 16.0±1.0

Simultaneous display of measurement units: displaying mg / dL & µmol / L in the meantime. Data Storage: 200 groups of measurement data
Average Calculation: It can measure the average value of 2-5 times
Start-up preparation time: Ready to use at startup, no preparation required
Battery voltage detection function: When the battery voltage of the tester is too low, the screen displays “Low Battery”

Automatic shutdown: Automatic shutdown after 10 minutes of non-working state

Battery display: Real-time display of battery power
Charging display: The viewing screen shows “Charging … ” during charging.
Automatic charging protection: It will stop charging automatically at the time battery voltage charging arrive 4.2V±0.05V.
